OLFLEX TORSION FRNC 16 G 1| Kiran Electronics

OLFLEX TORSION FRNC 16 G 1

Low Voltage (LV) power and control cable, Multicore for renewable energy applications, fixed and moving installation, indoor and outdoor use. Flame Retardant to IEC 60332-1-2 / IEC 60332-3-24 / IEC 60332-3-25, Halogen free, Oil Resistant, UV – Resistant, U0/U : 600/1000 V, 16 Cores, 1mm2, Number coded, unscreened, Polyolefin outer sheath colour Black, 14.8mm OD. Confirmed to CE, EAC, Approval – Fire protection, UL.

Download DATASHEET (PDF)
Product information (PDF)

Brand: Lapp

Description

Application Range

Stationary or Flexible
Torsion in Wind Turbines

Norm References / Approvals

UL AWM Style 21288

Product Make-Up

Extra-fine wire conductor made of bare copper
Core insulation: polyolefin compound
Outer sheath: special compound, halogen-free, black (RAL 9005)
Optional, overall shielding (D version) reducing electromagnetic interferences by tinned copper wire wrapping

Product Make-Up

Torsion resistant up to ±150 °/m for the drip loop of wind turbine generators
Resistant to weather, abrasion, temperature, sunlight (ISO 4892-2) and ozone (EN 50396)
Resistant to splashes of sea water as well as broad oil resistance, incl. EN 60811-404 and UL OIL RES I + II
Fire behaviour:- Halogen-free (IEC 60754-1);- Low corrosivity (IEC 60754-2);- Low smoke density (IEC 61034-2);- Highly flame retardant (IEC 60332-3-24 and -25; IEC 60332-1-2)
